E-180 RSX
super e-enduro/gravity electric mountain bike
“The E-180’s descending performance is virtually untouchable”
Go bigger, go faster – then go again
Our E-180 RSX is the chaos-crushing, downhill-dominating, climb-shrinking super electric mountain bike (e-MTB) for self-shuttled gravity riding, bike park play, and big mountain terrain. Engineered with our innovative low centre of gravity (CoG) design, it ‘plays and slays’ on the tightest, steepest tracks but still has your back when you’re flat out through boulder fields with handling that’s agile and alive for maximum fun, hour after hour, and run after run. If having the best time dropping in on the biggest terrain is why you ride, the E-180 RSX is ready.
Highlights
– Optimised low centre of gravity gives you untouchable gravity handling.
– 180mm front + 170mm rear of trail-dominating suspension travel.
– Multi-butted 6061 T-6 aluminium hydroformed frame is built to last.
– Bosch Performance CX 85Nm motor (600W peak power) for class-leading performance and reliability.
– 750Wh battery gives you the range to get more runs in between charges.
– MX wheels (29er front, 27.5in rear) so you can tackle everything full-gas – no matter how rowdy or steep.
Dressed to perform, zero compromises
To give you the best performance possible for when you’re pushing hard on the biggest terrain, we've equipped the E-180 RSX with 'sorted right from the box' parts selection headlined by Fox's impeccable Factory series suspension units front and rear; wireless electronic shifting across the 1x12 transmission from SRAM's X01 Eagle AXS; reliable and controllable braking power on even the longest, roughest descents with SRAM Code RSC four-piston hydraulic disc brakes (220mm front rotor; 200mm rear); eBike-tough DT Swiss wheels; and top-drawer Maxxis' dual-compound Assegai WT TR EXO+ tyres with Double Down Casing in the rear to shrug off the hardest knocks.
Engineered so you can commit
The E-180 RSX's frameset maximises the advantage of our unique tilted motor and super low-slung battery arrangement, which brings the bike’s centre of gravity as low as possible, to deliver you ultra-stable, dynamically centred and confident handling at any speed and on any terrain while short 155mm cranks deliver maximum pedal control and ground clearance.
Switchable geometry
Our Shape.It link ‘flip-chip’ allows you to change the geometry of the bike easily and quickly without affecting the suspension kinematics by raising or lowering the Bottom Bracket (BB) height. By using the shock extender and effectively moving the eye-to-eye length of the shock, the BB can be lifted or lowered – and all without affecting the suspension kinematics. Switch it between high and low positions to slacken the bike out by 0.6 degrees and lower the BB by 8mm so you can tailor the geometry to the terrain you're tackling.
The range – and reassurance – to get more from every ride
The extra-large 750Wh battery gives hour after hour, run after run on the biggest tracks and bike park lines, with a unique slide-out system for fast home charging removal and smaller battery options. Our innovative in-tube design is also far stronger and stiffer than open tube frames, surviving almost metric ton slam loads in testing so you can feel totally safe full-sending on the hill. Lifetime warranty bearings and full weather sealing back up ours and Bosch’s legendarily bombproof reliability. Because when a bike rides this great, downtime is a disaster.
“This is a true gravity-focused racer’s ebike, excelling at higher speeds on gnarly terrain”
Specifications
| COLOUR | Gloss orange with matte black | CASSETTE | SRAM XS-1275 T-Type Eagle, 10-52, 12 Speed |
|---|---|---|---|
| FRAME | 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing, Shape.it Link and 12mm X 148mm Boost Dropouts | CHAIN | SRAM GX T-Type Eagle, 12 Speed |
| FORK | Fox Float 38, Factory 29", 180mm Travel, 44mm Offset with Grip 2 Damper and custom tune, Tapered Steerer, Kashima Coating, 110mm x 15mm Boost, E-Thru Axle | CRANKSET | Race Face Affect E-Bike, 165mm, ISIS with T-Type Direct Mount 36T for Bosch Performance Line CX, Black |
| REAR SHOCK | Fox Float X2, Factory, independently adjustable Compression and Rebound damping, Kashima coating | BOTTOM BRACKET | N/A |
| HEADSET | FSA No. 55/35 Orbit 1.5 ZS, 1.8" Lower and 1 1/8" Upper Sealed Cartridge Bearings | SEATPOST | Crank Bro High-Line 3, 30.9mm, M/L 150mm Travel, XL 170mm Travel, High-Line Ball Socket Remote Lever |
| REAR HUB | DT Swiss Hybrid HX1700, 30mm wide rim, 12 x 148mm Boost, SRAM XD Steel | SADDLE | Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail |
| FRONT HUB | DT Swiss Hybrid HX1700, 30mm wide rim, 15 x 110mm Boost | HANDLEBAR | Race Face Turbine R, 35mm Rise, 35mm Bar Bore, 800mm Wide |
| SPOKES | DT Swiss | STEM | Race Face Atlas, 35mm Bar Bore, 35mm Extension |
| RIMS | DT Swiss Hybrid HX1700 | GRIPS | Whyte Lock-on Enduro Grip |
| TYRE | Maxxis Assigai WT, TR, 29" x 2.5" 120TPI, EXO + Sidewall Protection, 3C MaxxGrip, Dual Compound, Folding Bead, Front, Maxxis Assigai WT, TR, 27.5" x 2.5" 120TPI, Double Down Casing, 3C MaxxGrip, Dual Compound, Rear | BRAKES FRONT | SRAM Code RSC, 4 Piston with Sintered Metal Pads, 220mm Disc |
| SHIFT LEVERS | SRAM AXS Pod, 2 Button MMX, 12 Speed | BRAKES REAR | SRAM Code RSC, 4 Piston with Sintered Metal Pads, 200mm Disc |
| FRONT MECH | N/A | BRAKE LEVERS | SRAM Code RSC, MMX |
| REAR MECH | SRAM GX AXS T-Type 12 Speed | PEDALS | None |
| WEIGHT | 26.1kg (size M) |
Although we've taken every effort to ensure the accuracy of the information listed here sometimes things change so we reserve the right to change or update bike specifications, features, prices and colours as and when required.
eBike Specifications
| DRIVE UNIT | Bosch Performance Line CX (Smart System) drive unit with 85Nm maximum torque, 250W nominal power. Features four power settings including Tour+, that allows riders to focus on riding whilst being economical on power usage, and eMTB mode which automatically adjusts the motor's level of support to the terrain as you ride. | BATTERY | Bosch PowerTube 750Wh internal, perfectly integrated into the frame with an intuitive lockable mechanism for easy removal. Reaches full charge in less than six hours, and just over two hours for half charge. |
|---|---|---|---|
| DISPLAY | Bosch LED Remote allows for easy use and visibility as you ride, and also connects to Bosch’s eBike Flow App to give you even more insight and control over your bike. | CHARGER | 4A Compact Charger (230V) |
Please note: our custom motor covers are not currently compatible with the aftermarket Bosch eBike Alarm and Connect module to add bike tracking and alarm functionality to your Smart System bike
Geometry
| GEOMETRY | |||
|---|---|---|---|
| FRAME SIZE | Medium | Large | Extra Large |
| A - REACH (mm) | 455 | 483 | 510 |
| B - STACK (mm) | 631.5 | 645.1 | 658.6 |
| C - HEAD ANGLE (° degrees) | 63.2 (62.7) | 63.2 (62.7) | 63.2 (62.7) |
| D - SEAT ANGLE (° degrees) | 75.4 | 75.2 | 75 |
| E - BB HEIGHT (mm) | 349 (341) | 349 (341) | 349 (341) |
| F - WHEELBASE (mm) | 1255.5 | 1290.8 | 1324.6 |
| G - REAR CENTRE (mm) | 444 | 444 | 444 |
| H - STANDOVER HEIGHT (mm) | 769 | 770 | 772 |
| I - SEAT TUBE LENGTH (mm) | 420 | 445 | 470 |
| J - HEAD TUBE LENGTH (mm) | 100 | 115 | 130 |
